Side Mounted Tubular Tank Level Indicator
A straightforward and dependable device for direct level measurement in atmospheric or low-pressure tanks up to 5 kg/cm².
Available in lengths up to 3000 mm in a single piece.
WORKING PRINCIPLE:
The gauge is secured between two end blocks using gland packings and is installed parallel to the tank, forming a closed loop that allows the tank liquid to reach the same level in the indicator. Protective guards, such as tie-rods or C-channels, surround the gauge to prevent damage from accidental impacts. The end blocks include an integrated isolating valve, drain valve, and vent plug.
Side Mounted Tubular Tank Level Indicator
A straightforward and dependable device for direct level measurement in atmospheric or low-pressure tanks up to 5 kg/cm².
Available in lengths up to 3000 mm in a single piece.
WORKING PRINCIPLE:
The gauge is secured between two end blocks using gland packings and is installed parallel to the tank, forming a closed loop that allows the tank liquid to reach the same level in the indicator. Protective guards, such as tie-rods or C-channels, surround the gauge to prevent damage from accidental impacts. The end blocks include an integrated isolating valve, drain valve, and vent plug.
Specifications:
Title | Details |
|---|---|
Body | M.S./S.S./M.S. with FEP/PP Lined |
Tube | Borosilicate 19mm/25mmOD ON REQUEST |
Packing | Pure Teflon & Special Application- Silicon |
Flange Mounting | M.S./S.S./PP/SLIP ON |
Scale | Machine Engraved Aluminium/Acrylic/S.S. |
Temperature | 0-120 degree celcius |
Pressure | Full Vacum/6kg cm2 |
Specifications:
Title | Details |
|---|---|
Body | M.S./S.S./M.S. with FEP/PP Lined |
Tube | Borosilicate 19mm/25mmOD ON REQUEST |
Packing | Pure Teflon & Special Application- Silicon |
Flange Mounting | M.S./S.S./PP/SLIP ON |
Scale | Machine Engraved Aluminium/Acrylic/S.S. |
Temperature | 0-120 degree celcius |
Pressure | Full Vacum/6kg cm2 |
